Description
Securina SA6550D Dual View x ray baggage inspection system can display horizontal and vertical images by two independent generators, which can identify overlapping articles and contraband easily and precisely.
Securina SA6550D is middle capacity X-Ray scanning units are designed for the processing of higher quantities of packages or baggages in Goods In and mailroom settings.Dual X-ray Generator Security Inspection X Ray Baggage Scanner Machine with multi-energy X-ray scanner delivers a clear picture of hidden explosives, weapons, drugs and other contraband in hand-carried and small to mid-sized items. This dual-view x-ray scanner displays two separate, perpendicular X-ray images to provide a complete inspection in a single scan.
Securina SA6550D applications:
Cargo Screening; Passenger, Staff & Visitor Checkpoint Inspection; Corporate, Government & Private Security; Critical Infrastructure Security; Mail Screening
General specifications :
| Tunnel size | 650mm*500mm (W*H) | ||
| Conveyor speed | 0.22m/s | ||
| Conveyor height | 669mm | ||
| Maximum load | 160kgs(evenly distributed) | ||
| Wire resolution | 40AWG(dia 0.0787mm wire) | ||
| Spatial resolution | Level: dia1.0mm copper wire, Vertical: dia1.0mm copper wire | ||
| Penetration(steel) | 30mm guarantee, 32mm typical | ||
| Penetration resolution | 32AWG(0.202mm) | ||
| Display | 17inch(19inch in optional) color LCD monitor,high resolution: 1280*1024 | ||
| X Ray generator anode voltage | 140-160Kv | ||
| Cooling cycle | Oil Cooling /100% | ||
| X ray dose per inspection |
<1.0 μSv |
||
| X ray generator | 2 | ||
| Beam direction | top/side | ||
| Image process | Black and white / color, anti-color, high energy penetration, super enhancement, histogram equalization, forced scanning, magnifying glass, image pull back / front pull, image storage | ||
| Material classification | Organic:orange;Inorganic:blue;Mixed and light metal:green | ||
| Section and magnification | Any area selection,1 -64 times magnification, support continuous amplification | ||
| Image pull back | Can pull back 50 images | ||
| Storage capacity | Can store at least 100000 pcs image | ||
| X ray leakage | <0.5 μSv /h(at a distance of 5cm From external housing),meet all international and domestic health and safety standards | ||
| Film safety | guarantee ASA/ISO1600 Film | ||
| Software system |
F1,F2,F3 programmable key,high density alarm,TIP;date/time display, baggage Count, User management, System work timing, Radiation timing, self-inspection while power on, save and search image, automatically maintenance and diagnosis system, image recognition training. |
||
| Optional function |
Video surveillance system, LED prompt screen, bi-direction scan, voltage stabilizer, UPS back up |
||
| Physical size | 2456*1348*1331mm (L*W*H) | ||
| Weight | 750kgs | ||
| Operation temperature/Humidity | 0ºC~+40ºC+/-2ºC 5%~95%(non-condensing) | ||
| Storage Temperature/Humidity | -20ºC~+60ºC+/-2ºC 5%~95%(non-condensing) | ||
| Operation power | 220VAC (+/-10%) 50+/-3HZ | ||
| Power consumption | 1.0KvA | ||
| Noise | Less than 60db | ||
Securina Services :
1. Operation training program for end users
2. Free of factory training for engineer from agents to end user
3. Provide on-site trainning when customer requires
4. If quality problems happen in guarantee period, our company will maintain for free.
5. One year free spare parts and life time technical support
6. After-sales service isn't restricted by time and we will assign technical personnel to solve your problems immediately after receiving telephone and hear feedback idea of users and deal with them in time.
7. If you are caught in some problems when using our products, welcome to contact us at any time.
