Description

Securina SA4233(A) is a single mode, single energy 420 mm by 330 mm tunnel ultra-compact x-ray security screening system with superb image performance.Pseudo color scanning image and black&white scanning image disply.

Securina SA4233(C) is a dual mode, dual energy 420 mm by 330 mm tunnel ultra-compact x-ray security screening system with superb image performance.

Securina SA4233(C) adopt propietary X-ray image technique allowing the system to extract information about the object's atomic composition and material discrimination, resulting in the superior image quality.

By provided a small footprint and low weight, the compact SA4233 ve is ideal for screening small to medium size parcels, briefcases and packages at high threat locations including event security, prisons, government building, schools and commercial buildings.

SA4233 is very compact and low volume parcel X-ray for explosives, weapons and drugs. Light weight for better moving and put on the table or vehicles.

SA4233(A) Security x-ray machine General Specification:

1. Tunnel Size: 500(W)*300(H)mm
2. Conveyor Speed: 0.22m/s
3. Conveyor Max Load: 100kg
4. Dose per Inspection: <2.9μ Gy/h
5. Resolution: <0.101mm Metal Wire
6. Spatial resolution: Level: Dia1.0mm, Vertical: Dia1.3mm
7. Penetrate resolution: Dia 0.511mm
8. Penetration: 8-10mm Steel
9. Film Safety: Guarantee ISO1600 Film
10. X-ray Leakage: <0.1 μ Gy/h (at a distance of 5cm From external housing)

X-ray inspection system Generator:

1. Generate direct: Upward
2. Generate anger: 80 degree
3. Anode Voltage: 80Kv
4. Anode power: 0.2 to 1.0mA
5. Cooling / Duty Cycle: Oil Cooling /100%

Image System of x-ray inspection equipment:

1. X-ray Sensor: L-Shaped Photodiode Array (multi-energetic), 12bit Deep
2. Monitor: High Resolution Color, LCD Accord, 17 inch
3. Image Processing: Edge enhancement, image strengthening, image lightening, , reducing darkening, 4. Image returning, image retrieval.
5. Image Grey Level: 4096
6. Image Max Resolution: 1024 * 1280 pixel
7. Image Processing: 24bit for processing real time
8. Image storage: Storage 100000 pictures in real time
9. Zoom: 2, 4, 8, 16, 32, 64 Times Enlarge, Whole screen continuous observation
10. Multi-energetic distinguish objects: Organic objects in orange, inorganic objects in blue, mixture in green
11. High-energy/low energy: Switch from high energy to low energy
12. Assist to detect drug and explosive powder

X-ray inspection scanners of Installation Data:

1. Operation temperature/Humidity: 0º C-45º C/20%-95%(non-condensing)
2. Storage Temperature/Humidity: -20º C-60º C/20%-95%(non-condensing)
3. Operation Power: 220VAC(± 10%)50± 3Hz
4. Power Consumption: 1.0 KW (max), 0.3KW(working)
5. Noise: <55dB

Securina services:

1. We will provide pre sale advice and service as well as after sales advice and service.  We do all installations guide to meet your needs.

2. You may also request a call out and well inspect your current machine for any problems or repair requirements.

3. Make the trusted choice for security x-ray machine supplied by Securina.

4. Get professional service, wold class warranties, high quality security screening and detection system and expert advice with no hassle.
