Description

Securina SA5030A Single Energy X-Ray security inspection equipment is a economical security inspection device which makes use of the penetrating power of X-Ray to implement the rapid inspection of the packing baggage and goods.

Securina SA5030A is a compact X-Ray Inspection System with tunnel dimensions 50 x 30 cm . The SA5030A is the small system in the Securina X-ray System series and is designed for screening objects ranging from mailroom parcels to purses and backpacks.

Securina SA5030A x-ray inspection system recommend install at various checkpoint locations including government buildings, private hotels, and corporate mailrooms. Mounted on a compact frame with heavy duty roller casters, the SA5030A can be easily relocated to any site in need of an immediate screening solution.

Security x-ray machine General Specification:

1. Tunnel Size: 500(W)*300(H)mm
2. Conveyor Speed: 0.22m/s
3. Conveyor Max Load: 100kg
4. Dose per Inspection: <2.9μ Gy/h
5. Resolution: <0.101mm Metal Wire
6. Spatial resolution: Level: Dia1.0mm, Vertical: Dia1.3mm
7. Penetrate resolution: Dia 0.511mm
8. Penetration: 8-10mm Steel
9. Film Safety: Guarantee ISO1600 Film
10. X-ray Leakage: <0.1 μ Gy/h (at a distance of 5cm From external housing)

X-ray inspection system Generator:

1. Generate direct: Upward
2. Generate anger: 80 degree
3. Anode Voltage: 80Kv
4. Anode power: 0.2 to 1.0mA
5. Cooling / Duty Cycle: Oil Cooling /100%

Image System of x-ray inspection equipment:

1. X-ray Sensor: L-Shaped Photodiode Array (multi-energetic), 12bit Deep
2. Monitor: High Resolution Color, LCD Accord, 17 inch
3. Image Processing: Edge enhancement, image strengthening, image lightening, , reducing darkening, 4. Image returning, image retrieval.
5. Image Grey Level: 4096
6. Image Max Resolution: 1024 * 1280 pixel
7. Image Processing: 24bit for processing real time
8. Image storage: Storage 100000 pictures in real time
9. Zoom: 2, 4, 8, 16, 32, 64 Times Enlarge, Whole screen continuous observation
10. Multi-energetic distinguish objects: Organic objects in orange, inorganic objects in blue, mixture in green
11. High-energy/low energy: Switch from high energy to low energy
12. Assist to detect drug and explosive powder

X-ray inspection scanners of Installation Data:

1. Operation temperature/Humidity: 0º C-45º C/20%-95%(non-condensing)
2. Storage Temperature/Humidity: -20º C-60º C/20%-95%(non-condensing)
3. Operation Power: 220VAC(± 10%)50± 3Hz
4. Power Consumption: 1.0 KW (max), 0.3KW(working)
5. Noise: <55dB
