Securina-SA200 6 zones Door Frame Walkthrough Metal Detectors

Home Products Security Screening Equipment Walk Through Metal Detector Securina-SA200 6 zones Door Frame Walkth
Securina-SA200 6 zones Door Frame Walkthrough Metal DetectorsSecurina-SA200 6 zones Door Frame Walkthrough Metal DetectorsSecurina-SA200 6 zones Door Frame Walkthrough Metal Detectors

Securina-SA200 6 zones Door Frame Walkthrough Metal Detectors

  • Product Item:SA200
  • Detection zone: 6 zones
  • Display: small LCD screen
  • Display: LED alarming panel
  • Warranty: 1 year
  • Category:Walk Through Metal Detector
  • Inquiry Send Email Attachment

    Description

    LCD Screen 6-zones Walk-Thru Metal Scanning Gate-SA200

    Securina SA200 high sensitivity digital walkthrough metal detector use excellent electromagnetic testing and digital processing technology, has high detection sensitivity of the magnetic metal and nonmagnetic metal, and good recognition for personal items such as coins, keys, belt buckle, etc.

    Securina SA200 economical multi-zone walkthrough metal detector, high recognition rate to meet high flow inspection needs; professional production, advanced technology, uniform magnetic field distribution without detection blind spots;

    Securina SA200 metal detector door is the first real-world environment to interfere with real-time display (leading in the industry). And SA200 door frame metal detector is equipped with a small LCD screen display, also equipped LED location light accurately displays the hidden position of the contraband, keyboard operation is convenient and intuitive. SA200 security metal detector gate can adapt to high detection speed, adapt to the scene with large traffic, and meet all international electrical safety standards.

    Securina SA200 Walkthrough metal detector can detect metal accuracy range: ≥ 4G metal. System detection is automatically performed after power on. SA200 walkthru metal detector door has advanced environmental interference monitoring: the LCD panel displays the current usage environment interference in real time, in order to re-select the operating frequency or re-select the installation environment.

    Securina SA200 Multi-zone Walk Through Metal Detector also has the following features:
    ----Detection zone: 6 detection zone zones (12 independent probes)
    ----Mode for detecting alarms: simultaneous detection of multiple locations and accurate alarms
    ----Alarm indication: high brightness LCD screen and LED location alarm indication
    ----Overall sensitivity level: 0-200
    ----Sensitivity level of each zone: 0-200


    Technic specifications:

    Outer frame

    2220mm(H) x820mm(W)x500mm(D)

    Inner frame

    2000mm(H)x700mm(W)x500mm(D)

    Unit weight

    70KG

    Max distance

    0.3m at low sensitivity;0.5m at high sensitivity

    Electrical Current AC100V-240V  50/60Hz
    Power 12 W
    Work Environment -20 to +45 degree
    Sensitive adjustable 0-299
    Alarm sound and light
    Screen LCD in English menu
    Counting traffic and alarming
    Detecting Zones 6 zones
    Light bar

    LED panel on head box

    Operation way

    Keypad

    Sensibilty

    With the highest sensibility, it can detect the metal Article as small as the clip.
    With the range of 0-100, it can be adjusted the Sensibility easily, pre-set the weight, volume,
    size and location in respect of the metal Articles and eliminate the false alarming for the coin, key,
    jewelry, leather belt button, etc.

    Infrared counting

    The intelligent counter can calculate the number of the Passenger flow and the times of alarming.

    Detecting areas

    Allocation of six mutual over-lapping detecting areas, Simultaneous alarming
    from multi-areas and accurately ascertaining the location Of the metal articles according to
    the layout of the metal articles.

    Operation temperature/Humidity

    5C-40C / 0%-90%(non-condensin


    Functions:

    Walkthrough Metal Detector can easily detect dangerous items, knife, weapons and gun, and any metal article which is hidden in human body.

    Securina SA200 is your value for money economy option that still provides solid performance. Scanning from the archway to the floor it is highly sensitive to weapons. It has an added feature of scratch proof paint and hardy end caps. This unit will handle high volumes with limited damage over time.
